Sungold Solar All Black Solar Panels LEE-S-135W

Sungold Solar All Black Solar Panels LEE-S-135W

LEE 135W (strip) all black solar panels size is 540*1205*4mm, and the surface is coarse line ETFE (Z -grained). Anti -UV ability. The overall product design is thick, stable, and extremely exquisite. Lee 135W all black solar panels installation is extremely convenient. You can use adhesive to stick to the place you need to install, and to prepare multiple holes to adapt to your installation.

Description

LEE-S-135W all black solar panels adopt the conversion efficiency of imported back contact SunPower battery chips as high as 24.4%, which is very suitable for outdoor marine life. High weather resistance, high salt resistance, high corrosion resistance, high -resistant solar light plate. At the same time, the combination of glass fiber materials+double -sided ETFE materials ensures that the components are extremely stable and meet the extreme requirements of the marine field. They can be trampled and can also be used for irregular surfaces.

Product Features

LEE-S-135W Flexible Solar panel

back contact cell

Back contact cell

Adopt imported back contact cell design, efficiency up to 24.4%.Solid copper-silver paste, its thick copper base adds huge strength, almost no corrosio.The thick connector, built-in strain relief function can expand and deal with daily temperature fluctuations.

Ultra thin

Only 4mm thickness,LEE series flexible solar power panels are powerful, waterproof, lightweight, durable and highly resistant to the harsh operating conditions of the marine environment. Lightweight, about 50% of the glass frame. They’re a great option if you want a lot of power without sacrificing fuel economy, or if you don’t want any of the extra weight on the roof that might affect your center of gravity.

Ultra thin and waterproof
Double-sided ETFE and lightweight

Double-sided ETFE

The double-sided ETFE laminated outer film provides solar flexible panels with high weather resistance and has superior light transmittance and weather resistance, as well as heat resistance, corrosion resistance, and UV resistance. ETFE is also self-cleaning, ensuring optimum performance day in and day out.

Specially designed for marine use

The flexible marine solar panels designed with new materials are very resistant to salt spray and corrosion on the one hand, and the surface material of the components has a beautiful texture design, which fits the aesthetic design and is completely suitable for use with ships. On the other hand, the components are easy to install, and very suitable for marine, yacht and ship use. There is no need to worry about the power generation of components due to long-term erosion of the ocean, and no need to worry about the installation affecting the beauty of yachts or ships.

best marine flexible solar panels

Specifications

LEE-S-135W best marine flexible solar panels use sunpower solar cells with a conversion efficiency of up to 24.20%, which is very suitable for rv life. The absorption will be enhanced and the damage to the cell will be reduced.

ModelLEE-S-135W
Open-circuit voltage(Voc)26.2V
Voltage at Pmax(Vmp)22.3V
Short-circuit current(Isc)6.42A
Current at Pmax(Imp)6.05A
Cells efficiency(%)24.20%
The maximum system voltage100V DC(IEC)
Power temperature coefficient-0.32%/℃
Voltage temperature coefficient–1.8mv/℃
Current temperature coefficient0.05%/℃
Output power tolerance±3%
Operating temperature-20~75℃
Weight4.65kg
Size540*1235*4mm
Warranty1 year

FAQ

In order to pursue better high weather resistance, high salt spray resistance, high corrosion resistance and high aging resistance, LEE 135w solar panel specially uses the design of double-sided ETFE, and the overall resistance of the product is improved. This is a mature product. We have designed it for export for many years. Judging from the sales results over the years, the stability of this product is very high, and there are basically no after-sales problems.

LEE 135-watt lightweight solar panels can be used in all extreme environments where weather resistance is required. LEE 135w solar panels are recommended for yachts, RVs, offshore monitoring, off-grid systems for seaside buildings, plateau equipment, plateau camping, and outdoor travel. Stable power generation can make you trust in the most special environments.

If the modules are exposed to the sun for a long time, the cells are easily exposed to ultraviolet rays and the edges turn yellow, which is a normal phenomenon.

Camping trips, as a power bank on the tent. They can also be safely rolled and stored when not in use. (These are also called camping solar panels.)

Long trips in an RV. Of course, you can also bring a noisy generator to your power needs, or just enjoy a quiet drive with flexible solar panels mounted on your RV! Boating/fishing/fishing trips. Again, ditch the generator and let the fish be seduced by the serenity of the noise-free environment. (These are also called solar panels for ships, or “flexible solar panels of the ocean.”) Daily power backup. Do you find yourself constantly on the go, perhaps off the grid, panicking about your phone losing charge? Instead, you can attach a flexible solar panel to the top of your car and make it your slick, eco-friendly power source.

The reason may be that the battery is cracked, resulting in no voltage output.

Sungold solar was established in 2008, is a one of the leading wholesale solar panels suppliers in China.

Sungold solar focuses on manufacturing solar panels and keeps innovating processes. The products use specially developed patented materials and the latest solar cell technology to achieve higher conversion efficiency.

ModelLEE-SP-135W
Open-circuit voltage(Voc)26.2V
Voltage at Pmax(Vmp)22.3V
Short-circuit current(Isc)6.42A
Current at Pmax(Imp)6.05A
Cells efficiency(%)24.20%
The maximum system voltage100V DC(IEC)
Power temperature coefficient-0.32%/℃
Voltage temperature coefficient–1.8mv/℃
Current temperature coefficient0.05%/℃
Output power tolerance±3%
Operating temperature-20~75℃
Weight4.65kg
Size540*1235*4mm
Warranty1 year

1.What is the difference between a LEE 135W all black solar panels and other large watts of solar panels?

To pursue better high weather resistance, high salt spray resistance, high corrosion resistance, and high aging resistance, LEE series 135 watt solar panel especially uses the design of double-sided ETFE, but the overall resistance of the product is greatly improved.

This is a mature product, we have been designing and exporting it for many years. Judging from the sales results over the years, the stability of this product is very high, and there are no after-sales problems.

2.Which places are best equipped to equip this LEE 135 watt all black solar panels?

LEE 135 watt solar panel can be used in all places where weather resistance is required in extreme use environments.

The use of LEE 135 watt solar panel is recommended for yachts, RVs, offshore monitoring, off-grid systems for seaside buildings, plateau equipment, plateau camping, and outdoor travel. Stable power generation can make you trust in the most special environment.

Why does the edge of the panel cell turn yellow during the long-term use of the product?

If the modules are exposed to the sun for a long time, the cells are easily exposed to ultraviolet rays and the edges turn yellow, which is a normal phenomenon.

Why do some products have no power output?

The reason may be that the battery is cracked, resulting in no voltage output.

Why can you trust sungold solar’s solar panel products?

Sungold solar was established in 2008, is a one of the leading wholesale solar panels suppliers in china.

Sungold solar focuses on manufacturing solar panels and keeps innovating processes. The products use specially developed patented materials and the latest solar cell technology to achieve higher conversion efficiency.
