Sungold Portable Solar Panel SPC-TF-M-110W

Sungold Portable Solar Panel SPC-TF-M-110W

Model: SPC-TF-M-110W

Brand: Sungold

Weight: 3.5kg

Cell Efficiency: 22.60%

Folding Size: 565*550*15mm

Unfolding Size: 1305*560*4mm

Solar cell: Monocrystalline

Warranty: 1 year

Description

The Sungold SPC Series portable solar panel is one of the most powerful foldable solar panels on the market today. This SPC-TF-M-110W portable solar panel consists of 2 pieces of 55W portable solar panels and is approximately 51 inches long when open and only 22 inches long when folded. The SPC series portable solar panels are designed to be both convenient and practical. We use monocrystalline 166 solar cells with high output power and are compatible with mainstream portable power plants and various types of battery connections. It is practical and provides you with a perfect user experience.

Product Features

SPC-TF-M-110W portable solar panel

Monocrystalline 166 cells are used

Monocrystalline 166 solar cell

Sungold SPC-TF-M-110W uses A-grade monocrystalline 166 solar cells with an efficiency of 22.6%. It is only 0.6 inches (1.5 cm) thick when folded and weighs only 7.77 pounds (3.5 kg), making it the perfect choice for your emergency and outdoor life.

ETFE surface material

The portable solar panel is made of ETFE surface material, which is thinner and the surface is not easily scratched and is weather resistant. The surface also has a stronger light transmission and can absorb more sunlight. It is a ready-to-use solution for outdoor off-grid.

With ETFE surface material
Strongly compatible with portable power station

High compatibility

Sungold SPC series folding solar panel with Anderson plug and a variety of cable accessories available to meet a variety of portable power stations. It can quickly charge your smartphone, laptop, tablet, iPad, GPS, USB fan, camera, or other USB devices at the same time.

CE and ROHS certification

This portable folding solar panel is CE and ROHS certified to ensure the reliability of the solar panel and is suitable for charging a wide range of products to meet your daily needs. It is durable and has an IP65 waterproof rating.

CE and ROHS certification was carried out

Specifications

Sungold SPC series solar panels are the best portable solar panels for RVing or camping with lightweight and high output power. The folding solar panels can be used in off-grid environments, allowing you to enjoy the peace of the outdoors.

Maximum power(Pmax)

SPC-TF-M-110W

Open-circuit voltage(Voc)23.3V
Voltage at Pmax(Vmp)19.8V
Short-circuit current(Isc)5.89A
Current at Pmax(Imp)5.56A
Cells efficiency(%)22.60%
The maximum system voltage100V DC(IEC)
Power temperature coefficient-0.38%/℃
Voltage temperature coefficient-0.36%/℃
Current temperature coefficient0.07%/℃
Output power tolerance±5%
Operating temperature-10~60℃
Weight3.5kg
Size1305*560*4mm
Warranty1 year

FAQ

Solar panels are affected by light and angle. The angle of the light that illuminates the solar panel and the intensity of the light varies with the rotation of the sun. Please try testing the panels in full sunlight to ensure that no shadows are cast.

Yes, it is waterproof and has an IP65 waterproof rating, but only for temporary or emergency use. It is not designed for permanent installation or extended weather exposure, please do not leave them outside all the time at night or in bad weather.

The solar panel kit weighs only 7.77 lbs (3.5 kg) and is collapsible, measuring approximately 22 inches (56.5 cm) long, 21 inches (55 cm) wide, and 0.6 inches (1.5 cm) thick when folded. It is about 51 inches (130.5cm) long, 22 inches (56cm) wide, and 0.16 inches (0.4cm) thick when unfolded.

When using solar panels, it is normal for the actual power to fall short of the rated power. The power output of the solar panel is disturbed by the sunlight intensity, temperature, shading, etc.

No, you can’t do that. Different solar panels have different output voltages and currents, so when the panels are connected in parallel or series, the solar panels may be damaged.

Maximum power(Pmax)SPC-TF-M-110W
Open-circuit voltage(Voc)23.3V
Voltage at Pmax(Vmp)19.8V
Short-circuit current(Isc)5.89A
Current at Pmax(Imp)5.56A
Cells efficiency(%)22.60%
The maximum system voltage100V DC(IEC)
Power temperature coefficient-0.38%/℃
Voltage temperature coefficient-0.36%/℃
Current temperature coefficient0.07%/℃
Output power tolerance±5%
Operating temperature-10~60℃
Weight3.5kg
Size565*550*15mm
Warranty1 year

How to get higher power?

Solar panels are affected by light and angle. The angle of the light that illuminates the solar panel and the intensity of the light varies with the rotation of the sun. Please try testing the panels in full sunlight to ensure that no shadows are cast.



Are the SPC Series portable solar panels waterproof? Can these solar panels be permanently installed outdoors?

Yes, it is waterproof and has an IP65 waterproof rating, but only for temporary or emergency use. It is not designed for permanent installation or extended weather exposure, please do not leave them outside all the time at night or in bad weather.



What are the dimensions of the Sungold SPC-TF-M-110W folded and unfolded?

The solar panel kit weighs only 7.77 lbs (3.5 kg) and is collapsible, measuring approximately 22 inches (56.5 cm) long, 21 inches (55 cm) wide, and 0.6 inches (1.5 cm) thick when folded. It is about 51 inches (130.5cm) long, 22 inches (56cm) wide, and 0.16 inches (0.4cm) thick when unfolded.



Why does my solar panel not reach its rated power of 110W?

When using solar panels, it is normal for the actual power to fall short of the rated power. The power output of the solar panel is disturbed by the sunlight intensity, temperature, shading, etc.



Can I connect the Sungold SPC-TF-M-110W solar panel in parallel or series with other brands of solar panels?

No, you can’t do that. Different solar panels have different output voltages and currents, so when the panels are connected in parallel or series, the solar panels may be damaged.
